Storefront Glazing Systems
Looking for storefront glazing systems designed to support energy efficiency, durability, and different job conditions? Architectural Glass and Metal provides access to center glazed and offset glazed storefront systems for commercial, residential, and light commercial applications.
Available in five storefront series, these glass and aluminum systems are manufactured to accept a range of glass types, including high-performance glass, insulated glass units, and laminated glass. With compatible framing products, aluminum doors, hardware, and stock lengths, these storefront glazing systems help contractors and installers source complete project-ready solutions.
5 Series for High Performance
Storefront glazing systems are used to create durable, functional, and visually clean glass and aluminum entrances for businesses, homes, retail spaces, offices, and other architectural projects.
These storefront systems include a complete line of storefront stock lengths to help simplify fabrication and installation. Extruded from 6063-T5 aluminum alloy, the framing sections provide strength, durability, and consistent performance for a range of storefront applications.
Available finishes include clear anodized and bronze anodized, allowing the framing sections to coordinate with different exterior and interior entrance designs.
Storefront glazing systems can be configured with traditional center glazing or offset/front-set glass. Depending on the selected system, they can accommodate insulated glass, laminated glass, and other storefront glass types.
When paired with the right high-performance glass, storefront systems can help support energy efficiency, structural performance, impact resistance, and better management of air and water infiltration. Final performance depends on the glass make-up, framing system, installation, and project requirements.
These framing materials are also designed to work with a variety of storefront products, including aluminum doors, storefront hardware, handles, and compatible glass options. This gives architects, contractors, glaziers, and installers greater flexibility when specifying complete storefront assemblies.
Center Glazing Systems
Center glazed storefront systems are commonly used for storefronts, entrances, and glass wall applications that require a clean framing profile and reliable performance.
Available center glazed systems include the 250, 400, and 450 Storefront Series, each designed for different glass thicknesses, frame dimensions, performance needs, and compatible storefront products.
205, 400 & 450 Center Glazed Systems: Features, Specs & Compatible Products
250 Storefront Series Center Glazed System:
- Features:
- Cost effective center glazing system
- Increases energy efficiency
- Designed specifically for insulated glass units
- Specifications:
- Glass thickness: 1″
- Glass pocket width: 1 ¼”
- Framing sections: 2″ x 4 ½”
Compatible 250 Series Products:
- Wide array of aluminum doors using a filler insert
- Large assortment of storefront hardware
- Included Storefront Stock Lengths:
- Head & sill assemblies
- Horizontal assembly
- Corner post
- Wall jamb
400 Storefront Series Center Glazed System:
- Features:
- Center glazing system with optimal versatility
- Meets industry standard performance requirements
- Accommodates nearly any storefront design
- Specifications:
- Glass thickness: ¼”
- Glass pocket width: ½”
- Framing sections: 1 ¾” x 4″
Compatible 400 Series Products:
- All aluminum doors with single or double action hardware
- All standard storefront hardware
- All storefront glass types
- Included Storefront Stock Lengths:
- Head, sill & horizontal assemblies
- Corner post
- Door jamb
450 Storefront Series Center Glazed System:
- Features:
- Flexible, center glazing system for exterior applications
- Meets higher performance standards
- Also suitable for interior applications
- Specifications:
- Glass thickness: ¼”
- Glass pocket width: ½”
- Framing sections: 1 ¾” x 4″
Compatible 450 Series Products
- All aluminum doors with single or double action hardware
- All standard storefront hardware
- All storefront glass types
- Included Storefront Stock Lengths:
- Head, sill & horizontal assemblies
- Corner post
- Vertical mullion
Offset Glazing Systems
Offset glazed storefront systems are designed for projects that require the glass position to sit toward the interior or exterior side of the frame.
These systems are useful for storefronts, entrances, and glazing applications where insulated glass unit compatibility, energy performance, or custom glass positioning is important.
Available offset glazed systems include the 251 and 251DT Storefront Series, both designed to support complete glass and aluminum storefront assemblies.
251 & 251DT Offset Glazed Systems: Features, Specs & Compatible Products
251 Storefront Series Offset Glazed System:
- Features:
- Offset glazing system designed to reduce energy costs
- Manufactured specifically for insulated glass units
- Equipped with adjustable glass inserts for custom applications
- Specifications:
- Glass thickness: 1″
- Glass inserts: Can be positioned inward or outward
- Framing sections: 2″ x 4 ½”
Compatible 251 Series Products:
- Most aluminum doors
- Large selection of storefront hardware
- Included Storefront Stock Lengths:
- Head assembly
- Sill assembly
- Horizontal assembly
- Vertical mullion
251DT Storefront Series Offset Glazed System:
- Features:
- High performance commercial grade offset glazing system
- Thermally broken frames prevent heat transfer
- Weatherstripping minimizes air infiltration
- Specifications:
- Glass thickness: 1″
- Glass inserts: Can be positioned inward or outward
- Framing sections: 2″ x 4 ½”
Compatible 251DT Series Products:
- Most aluminum doors
- Huge array of storefront hardware
- Included Storefront Stock Lengths:
- Head assembly
- Sill assembly
- Horizontal assembly
- Vertical mullion
Increase Energy Efficiency with Storefront Glazing Systems
Center glazed and offset glazed storefront systems offer flexible options for commercial and residential glazing applications.
With multiple series, insulated glass compatibility, anodized finishes, stock lengths, aluminum door compatibility, and storefront hardware options, these systems can help support efficient project planning and complete storefront assemblies.
For storefront glazing system specifications, series selection, glass compatibility, estimates, or order support, contact Architectural Glass and Metal directly.
